Configuration: 802.3af compliant PoE ports x 4
10/100/1000Base-TX x 2, Auto MDI/MDI-X, Auto-Negotiation
Cable: 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cables (100 m), 100 Base-TX: 2/4-pair UTP/STP Cat. 5 cables (100 m), 1000 Base-T: 4-pair UTP/STP Cat. 5 cables (100 m)
Diagnostic LED: Power (Green) x1, Fault alarm (Red) x1, PoE (Orange) x8, Link/Activity(Green) x8, Full duplex/Collision (Orange) x8, Gigabit Copper: Link/Act (Green) x2, Gigabit Copper: Speed (Orange) x2
Relay Alarm: Dry Relay output with 1 A @ 24 V ability
PoE Technology: Alternative B
Transfer Rate: 14.880 pps for 10M Ethernet, 148.800 pps for 100M Fast Ethernet, 1.488,100 pps for Gigabit Ethernet
Transfer packet size: 64 bytes to 1522 bytes (with VLAN Tag)
MAC Address: 8K
Packet Buffer: 1 Mbits
Power: 48V DC for PoE with reversed protection, Isolated power input
Power Consumption: 30 Watt without PoE loading
95 Watt with full PoE loading
Construction: Rugged Aluminum Alloy Chassis, IP31 protection
Mounting: DIN-Rail mount
Dimensions: 149(H) x 131(W) x 66(D) mm
Weight: 1.05 kg
Operating Temperature: –25 to +70 °C, 5 to 95% RH
Storage Temperature –40 to +80 °C, 5 to 95% RH
EMI: FCC class A, CE/EN55022 Class A
EMS: EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4 11
Shock: IEC60068-2-27 (50 g peak acceleration)
Railway: EN 55022 Class A
Vibration: IEC60068-2-6 (5 g / 5 ~ 500 Hz / random operation)
Standard: IEEE802.3 10Base-T, IEEE 802.3u 100Base-T Fast Ethernet, IEEE 802.3ab 1000Base-T, IEEE802.3x Flow Control and Back-pressure, IEEE 802.3af Power Over Ethernet, IEEE 802.1p Class of Service
PoE output voltage: DC 48 V
Switch Technology: Store and Forward Technology with 32 Gbit/s Switch Fabric
