Data transfer speed: 0.3Kbps to 250Kbps
Maximum data transmission distance: 120Km
Minimum output power converter: -20dBm
Sensitivity to receiving information: -31dBm, -33dBm, -34dBm
Wavelength: 1550nm, 1310nm
Maximum power consumption: 30W
Power Consumption (Output Adapter): 24V DC, 1.3A
Power Input Plugin ( Redundant ): Yes
1000Mb SFP Fiber optic (Gigabit) Ports: 2 LC Duplex or LC Simplex ports
100Mb SFP Fiber optic (Megabit) Ports: 2 LC Duplex or LC Simplex ports
Serial port: RS-232 terminal
MTBF: 500,000 hour
Dimensions: 35x121x119mm
Installation: Din-rail
Isolation: RS-232 port and Terminal Status
Operating Temperature: -40 to 60 ° C
Standards and Certifications: EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4, EN 55022, EN 55024, FCC part 15 Class A, EN 50121-4, IEC 62236-4, EN 60950-1, IT equipment, EN 60079-0, EN 60079-15, EN 61000-4-2, IEC 61000-4-3, ENV 50204, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-9, EN 61000-4-11, EN 61000-4-16
Storage Temperature: -40 to 60 ° C
LED Per Port: Yes
Power: Yes
Hardware installation guide: Yes
