10/100/1000BaseT(X) Ports: 2 x 10/100/1000/2.5G Base-T Ports, 2 x M12 X-coded connectors
Frequency Band: 2.400 to 2.4835 GHz (2x2 MU-MIMO), 5.150 to 5.350 GHz, 5.470 to 5.725 GHz, 5.725 to 5.875 GHz (2x2 MU-MIMO)
Wireless Security: WPA2-Personal (CCMP), WPA2-Enterprise, WPA3-Personal (SAE/OWE), WPA3-Enterprise (Suite-B), 802.11w, 802.1X, SecureBoot (TPM), Security Log (persistent)
WLAN Antenna Connector: 2 x QMA compatible antenna connector for Wi-Fi 6 2.4 GHz and 5 GHz (combiner)
Security: VPN: SSL Server/Client, IPsec, OpenVPN Client, Wireguard, GRE/GRETAP, VXLAN
WLAN Operation Mode: Access Point, Client, Bridge
WLAN Standards: IEEE 802.11g, 802.11a, 802.11n, 802.11ac, 802.11ax
Transmission Rates: 2.4 GHz: Up to 802.11ax 40 MHz 2SS BW HE11: 573 MBit/s, 5 GHz: Up to 802.11ax 80 MHz 2SS BW HE11: 1201 MBit/s
Connector: M12 A-coded male
Power Consumption: 14 W
Input Voltage: PoE Class 4 (IEEE 802.3at type 1 and 2 PD)
Reverse Polarity Protection: Supported
Humidity: 5-95% relative humidity
Dimensions Packaged: 195 x 70 x 111 mm (7.68 x 2.76 x 4.37 inches)
Weight (PACKAGED): 1.45 kg without antennas
Housing: Full metal
Installation: Screw mounting
Standards and Certifications: Ingress protection: IP66; Climate: EN 50155, class OT4 Railway applications - Electronic equipment used on rolling stock; EMC: EN 50155, Railway applications - Electronic equipment used on rolling stock, EN 50121-3-2, Railway applications – Electromagnetic compatibility, Part 3-2: Rolling stock – Apparatus, ETSI EN 301 489-1, Electromagnetic compatibility (EMC) and Radio spectrum Matters (ERM) for radio equipment and services - Part 1: Common technical requirements, ETSI EN 301 489-17, Electromagnetic compatibility (EMC) and Radio spectrum Matters (ERM) for radio equipment - Part 17: Specific conditions for Broadband Data Transmission Systems; Mechanical (Shock and vibration): EN 61373, category 1, class B; Insulation (Coordination and test): EN 50155, Railway applications - Electronic equipment used on rolling stock; Radio communication: ETSI EN 300 328, Wideband transmission systems; Data transmission equipment operating in the 2.4 GHz ISM band and using wide band modulation techniques, ETSI EN 301 893, 5 GHz RLAN, ETSI EN 300 440, 5.8GHz, Short Range Devices, IEEE802.11, Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications; Safety: EN/IEC 61010-1, Safety requirements for electrical equipment for measurement, control, and laboratory use, EN 45545-2, Fire protection on railway vehicles; Shock: IEC 60068-2-27, IEC 61373, MIL-STD-810G; Vibration: IEC 60068-2-64, IEC 61373
Operating Temperature: -40 to +70°C (-40 to +158°F)
Storage Temperature: -55 to +85°C (-67 to +185°F)
Management: SNMP v2c/v3 with USM authentication and encryption support, HTTP/HTTPS web interface, and WebAPI with user authentication (local or LDAP), CLI (SSH and Telnet), Certificate Management (SCEP), Dual Firmware Primary/Backup
LED Indicators: DC, ON, X1, X2
MTBF: 538,000 hours
