LAN: 5x 10/100/1000BaseT(X), RJ45
Power Input: 3-pin male/ignition contact
Reset Switch: available on the front panel
Software: Linux OS OpenWrt
System Architecture: Dual-Core CPU T1023, 1200 MHz 1 GB RAM, 128 MB Flash
Antenna connectors: QLS connectors
USB host: USB Type-A, USB 2.0
3G Bands: B1, B2, B3, B4, B5, B8
4G (LTE) Bands: B1, B2, B3, B4, B5, B7, B12, B13, B20, B25, B26, B29, B30, B41
Antenna: with Diversity and MIMO
Transfer Rates: up to 300 Mbps download / 50 Mbps upload
Encryption: AES, TKIP, WPA, WPA2, WPA3
Frequency Range: 2.412 GHz to 2.472 GHz, or 4.920 GHz to 5.825 GHz, selectable band
Operational Feature: up to 128 clients per radio
Security: stateful firewall with multi-level client isolation
Transfer Rates: up to 1300 Mbps
Accuracy: up to 1.5 m
Frequency Band: GPS (L1), GLONASS (L1, FDMA), Galileo (E1) ready, Beidou
Protocol Standards: NMEA, RTCM 104
Time To First Fix: cold start < 35 s, warm start 1 s
Interruptions of Voltage Supply: compliant with ISO 16750-2
Power Supply: 12 to 24 VDC, wide-range power supply (compliant with E1)
Power consumption: 12 W typ., 30 W max
Ambient Temperature: depending on the temperature class of the Wi-Fi module -40.. +75 °C operating or -25.. +75 °C operating (+65 °C operating when using an SSD)
Humidity: max. 95 % non-condensing operating and storage
Housing: IP40, aluminum, wall mount, conductive cooling
Dimensions: 251 (284) mm x 70 mm x 170 mm (w h d) (width mounting points)
Weight: up to 2800 g
Storage Temperature: -40.. +85 °C
Standards and Certifications: ISO 16750-1, -2, -3, -4, -5
